Industrial Cylinders
We maintain the highest standards for all compressed gas cylinders used in storage, shipping, and dispensing.
Central Welding Supply offers a complete range of cylinder products tailored to your exact application needs. Have questions? Our experienced team is always here to help you find the right solution.
Acetylene Cylinders
| Size/Name | Cubic Ft | Width | Height | Weight |
|---|---|---|---|---|
| MC | 10 CF | 4" | 15" | 8 LBS |
| B | 40 CF | 6" | 23" | 25 LBS |
| 75 | 75 CF | 7" | 31" | 43 LBS |
| #4 | 145 CF | 8" | 38" | 74 LBS |
| #5 | 397 CF | 12" | 47" | 169 LBS |
High Pressure Steel Cylinders
| Size/Name | Cubic Ft | Width | Height | Weight |
|---|---|---|---|---|
| 21 | 21 CF | 5" | 17" | 10.5 LBS |
| 46 | 46 CF | 7" | 18" | 27 LBS |
| 55 | 55 CF | 7" | 23" | 32 LBS |
| 80 | 92 CF | 7" | 32" | 46 LBS |
| 125 | 125 CF | 7" | 43" | 62 LBS |
| 150 | 155 CF | 7.5" | 46.5" | 67.5 LBS |
| 250 | 251 CF | 9.25" | 51" | 115 LBS |
| 300 | 336 CF | 9.25" | 55.5" | 134 LBS |
Cylinders are defined by four main characteristics:
Gas form - Compressed gas, refrigerated liquid (carbon dioxide, nitrous oxide), dissolved gases (acetylene), or cryogenic liquids.
Gas type - Oxygen, nitrogen, argon, acetylene, carbon dioxide, hydrogen, helium, rare gases, specialty gases, nitrous oxide, chemical gases and liquids, medical gases.
Gas purity - Up to 99.9999%.
Cylinder - Size (volume) and pressure, varying from country to country.
Cylinders are available as individual units or manifolded into 6-pack and 16-pack bundles for high-volume, unified dispensing.
We offer a full range of construction materials to match your operational requirements:
Standard & Specialty: Steel, aluminum, and high-strength light alloys
Composite Solutions: Advanced lightweight composite materials
Specialized Interiors: Porous mass interiors designed specifically for acetylene stability and safety
Need higher volume than a 16-pack? Explore our Bulk & Micro-Bulk Gas Systems
Department of Transportation (DOT) Compliance & Cylinder Testing:
Per DOT regulations, all compressed gas cylinders must be re-tested every 5 years. You can find the DOT number and the date of the last test stamped directly on the upper "shoulder" of the cylinder.
Standard Re-Test: Every 5 years
10-Year Extension: If a five-pointed star ($\star$) follows the date, the cylinder does not require testing for 10 years.
Have questions about your cylinder's test date? Contact your local Central Welding Supply Store and our team will be happy to help.
Non-refillable Steel Cylinders
A convenient and cost-efficient way to handle calibration gas mixtures... these smaller-sized, lightweight cylinders require no deposit or monthly rental charge. They are easier to handle, less expensive to ship, and use very little space. They also eliminate over-purchasing when only small quantities are necessary.
These steel cylinders are recommended for non-reactive gas mixtures and pure gases such as argon, helium and nitrogen. They combine a convenient, portable size with a wide range of capacities (from 17 liters (0.6 cu ft.) to 550 liters (19.4 cu ft.)) to handle any field calibration requirement.
17 Liter Cylinder
Contents:17 liters (0.6 cu. ft.)
Pressure:240 PSIG
Outlet:CGA 600
Weight:1.1 lbs.
Dimensions:3” x 10 3/4”
D.O.T. specs:39 NRC
Regulator:400 Series
22 Liter Cylinder
Contents: 22 liters (0.8 cu. ft.)
Pressure: 240 PSIG
Outlet: CGA 160 (1/8” NPT-F)
Weight: 2.15 lbs.
Dimensions: 3” x 14 1/4”
D.O.T. specs: 4B240ET
Regulator: 700 Series
34 Liter Cylinder
Contents: 34 liters (1.2 cu. ft.)
Pressure: 500 PSIG
Outlet: CCGA 600
Weight: 1.4 lbs.
Dimensions: 3" x 10 3/4"
D.O.T. specs: 39 NRC
Regulator: 400 series
103 Liter Cylinder
Contents: 103 liters (3.6 cu. ft.)
Pressure: 1000 PSIG
Outlet: C-10 5/8”-18 UNF
Weight: 2.3 lbs.
Dimensions: 3 1/4” x 13 2/3”
D.O.T. specs: 39 NRC
Regulator: 500,6000,8000 Series
221 Liter Cylinder
Contents: 221 liters (7.9 cu. ft.)
Pressure: 260 PSIG
Outlet: CGA 165
(1/4” SAE flare 45°)
Weight: 6.3 lbs.
Dimensions: 9” x 16 1/2”
D.O.T. specs: 39 NRC
Regulator: 700 Series
550 Liter Cylinder
Contents: 550 liters (19.6 cu. ft.)
Pressure: 2200 PSIG
Outlet: Varies with the gas
Weight: 12.9 lbs.
Dimensions: 4 1/6” x 20 1/2”
D.O.T. specs: E8990 NRC
Regulator: 6000,900,HP Series
Portable Reactive Gas Cylinders
Offering mixture stability in a lightweight, portable package. These compact, lightweight aluminum cylinders are recommended for gas mixtures that are not stable in steel cylinders. Typical components blended in these packages include ammonia, chlorine, hydrogen sulfide, nitric oxide, nitrogen dioxide and sulfur dioxide. They are available in capacities from 11 liters (0.4 cu. ft.) to 104 liters (3.7 cu. ft.) and are conveniently transported in a NorLab carrying case or bag. They are non-refillable, except the “3A” cylinder, which is a refillable package.
Bump Gas Cylinder
Used for Industrial Hygiene Bump Gas Mixtures.
Contents: 11 liters (0.4 cu. ft.)
Pressure: 140 PSIG
Outlet: Trigger-style aerosol
Weight: 0.3 lbs
Dimensions: 2 7/8” x 12”
D.O.T. specs: 39 NRC
Regulator: N/A
34 Liter Cylinder
Contents: 34 liters (1.2 cu. ft.)
Pressure: 500 PSIG
Outlet: C-10 5/8”-18 UNF
Weight: .8 lbs.
Dimensions: 2 7/8” x 11 1/2”
D.O.T. specs: 39 NRC
Regulator: 500,6000,8000 series
48 Liter Cylinder
Contents: 48 liters (1.7 cu. ft.)
Pressure: 300 PSIG
Outlet: CGA 165
Weight: 1.75 lbs.
Dimensions: 4” x 16 1/4”
D.O.T. specs: 39 NRC
Regulator: 700 Series
58 Liter Cylinder
Contents: 58 liters (2.0 cu. ft.)
Pressure: 500 PSIG
Outlet: C-10 5/8”-18 UNF
Weight: 1.6 lbs.
Dimensions: 3 1/2” x 14 1/2”
D.O.T. specs: 39 NRC
Regulator: 500,6000,8000 Series
Chlorine Cylinder - 58 Liter
Contents: 58 Liters (2.0 cu. ft.)
Pressure: 500 PSIG
Outlet: C-10 5/8” - 18 UNF
Weight: 1.6 lbs.
Dimensions: 3 1/2” x 14 1/2”
D.O.T. specs: 39NRC
Regulator: 517SS (0.5 ltr./min.) 518SS (1.0 ltr./min.)
76 Liter Cylinder
Contents: 76 liters (2.6 cu. ft.)
Pressure: 500 PSIG
Outlet: CGA 170
Weight: 1.75 lbs.
Dimensions: 4” x 16 1/4”
D.O.T. specs: 39 NRC
Regulator: 900 Series
"3A" Cylinder (Refillable)
Contents: 104 liters (3.7 cu. ft.)
Pressure: 1800 PSIG
Outlet: CGA 180
Weight: 2.2 lbs.
Dimensions: 3 1/4" x 12 1/4"
D.O.T. specs: 3AL 1800
Regulator: 900 Series
